Kenwood KT-5300

AM/FM Stereo Tuner (1976-79)

Description

Designed to match the KA-5500, KA-3500 and KA-1500 amplifiers, the Kenwood KT-5300 represents outstanding value for money.

Specifications

Type: Mono/Stereo Tuner

Tuning Bands: FM, MW

Tuning Scale: Analogue

FM Tuning Range: 88 to 108 MHz

MW Tuning Range: 525 to 1605 kHz

Sensitivity: 1.9uV (FM), 20uV (MW)

Signal to Noise Ratio: 70dB (FM), 50dB (MW)

Distortion: 0.4% (FM), 0.9% (MW)

Selectivity: 60dB (FM), 35dB (MW)

Frequency response: 30Hz to 15kHz (FM)

Output: 700mV (FM), 150mV (MW)

Dimensions: 380 x 140 x 255mm

Weight: 5.3kg

Year: 1976
